میکروسکوپ زیست شناسی اینورت بوئکو (MODEL : BIB-100T - (BOECO
توضیحات
Optical System: Infinite corrected system, field diameter 22 mm
Viewing Head: Bin- or Trinocular Head, 30° inclined, 360° rotatable, Interpupillary Distance 48 - 75 mm
Nosepiece: Quintuple revolving nosepiece
Eyepiece: High-point, Extra Wide Field Eyepiece EW 10X /22 mm
Objectives: LWD Infinite corrected Plan Achromat Objective 4X/0,1 WD 28 mm
LWD Infinite corrected Plan Achromat Objective 40X/0,6 WD 2.1 mm
Infinite corrected Plan Achromat Phase Objective 10X/0,25 WD 10 mm
Infinite corrected Plan Achromat Phase Objective 20X/0,4 WD 5.1 mm
Condenser: ELWD condenser N.A. 0,3. LWD 72 mm (without condenser 150 mm)
Centering: Centering Telescope 30 mm diam. Telescope Phase Annulus 10X - 20X Phase Annulus Plate
Stage: Plain Stage 160 x 250 mm, Glass Insert Auxiliary Stage 70 x 180 mm Attachable Mechanical Ruler
Focusing: Coaxial coarse and fine adjustment. Vertical objective movement, Coarse stroke 37.7 mm per rotation, Fine Stroke: 0,2 mm per rotation
Filter: Diameter 45 mm, blue, green and ground glass
Illumination: 3W LED lamp, brightness adjustable.
Body: Innovative stand structure
Power: Inbuilt power supply 100-240V, 50/60Hz Weight: Net weight 11,0 / 11,7 kgs.
Supplied with: Dust cover, immersion oil and instruction manual
